Floor-Standing Dual Gun DC Fast Charger 30kW-60kW | VC Series EV Charging Station
Our VC Series floor-standing dual-gun DC fast charging station offers 30kW,40kW and 60kW power options, designed for commercial public EV charging projects. This dual-gun charger supports two electric vehicles charging at the same time, greatly improving parking charging throughput and revenue. With compact footprint and high cost-performance, it adopts IP54 dustproof & waterproof rating. Built-in full protection functions including under-voltage, over-voltage, under-current, over-current and lightning surge protection, stable operation between -20℃ ~ +50℃. Equipped with a 7-inch color touchscreen and RFID card reader, it supports multiple charging modes: RFID card, mobile APP and manual start. Compatible with OCPP1.6 protocol, optional CAN/ Ethernet /4G network. We support customized connector combinations(CCS/GB/CHAdeMO/NACS), multi-language UI and OEM/ODM service. CE certified and Ping An insured, it is ideal for hotels, shopping malls, office parks, residential communities and fleet depots.
5.0
like
Model:
VC30750
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Product Introduction
Exquisite Design Small size & footprint, high cost-performance, flexible UI design.
Technical Support Custom dual-plug combinations, multi-language screen, OCPP & cloud charging compatible, OEM/ODM available.
IP54 Protection Rating Under/over voltage, under/over current & lightning surge protection.
parameter
| parameter | VC30750 | VC40750 | VC60750 | FC60750 | FC120750 | FC150750 | FC180750 |
|---|---|---|---|---|---|---|---|
| Rated power | 30KW | 40KW | 60KW | 60KW | 120KW | 150KW | 180KW |
| Input voltage | AC380V±20% / 480V±20% optional | ||||||
| Input Current | 45A | 60A | 95A | 95A | 190A | 230A | 285A |
| Output voltage | 200-750V(200-1000V optional) | ||||||
| Output Current | 100A | 120A | 200A | 0-200A | colspan="3" | 0-250A | |
| Frequency | 45-60 HZ | ||||||
| Gun quantity | colspan="7" | 2 | |||||
| Charging way | Quick or Slow charge automatic switch | ||||||
| charging mode | SWIPE CARD, APP, MANUAL | ||||||
| Cable length | 5M | ||||||
| Interface | 7" COLOR TOUCH SCREEN + IC CARD CONTACTLESS CARD READER | ||||||
| Network connection | Standard：CAN/485/Ethernet；Optional：GPRS/4G/WiFi | ||||||
| Size (mm) | 1350×690×240 | 1350×690×240 | 1350×690×240 | 1750×620×780 | 1750×620×780 | 1750×620×780 | 1750×620×780 |
| Weight | 100KG | 100KG | 100KG | 200KG | 230KG | 310KG | 310KG |
| Operating Temperature | -20℃ ~ +50℃ | ||||||
| Altitude | 2000M | ||||||
| IP LEVEL | IP54 | ||||||
| Humidity | 5%-90%RH, non-condensing | ||||||
Application Scenario
