High Efficiency 3.6KW 5KW Solis Single Phase Grid-Tied Inverters with Advanced Monitoring Features
Our High Efficiency 3.6W 5KW Solis Single Phase Grid-Tied Inverters are equipped with advanced monitoring features, allowing for optimal performance and ease of maintenance. With our strong company reputation and proven product performance, you can trust in the reliability and effectiveness of our inverters for your solar power system.
5.0
like
Model:
Solis-1P 3.6KW-5KW-4G-US
power:
3.6kW 5kW
Product Name:
Single Phase Grid-Tied Inverters
Brand Name:
Solis
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Product name
3.6KW 5KW Solis Single Phase Grid-Tied Inverters
Rated voltage
330V
Surge protection
DC Type III / AC Type III
Ingress protection
TYPE 4X
Rated grid frequency
60Hz
Max. operation altitude
13,120 ft (4000 m)
Communication
RS485, Optional: Cellular, Wi-Fi
Cooling concept
Natural cooling
Max. Efficiency
97.3%
Warranty
10 YEARS
Weight
15kgs
Dimension (L*W*H)
353 × 810 × 165 mm
Operating Temperature
-13°F to 140°F (-25°C to 60°C )
Application
Solar system
Product Features
- Max. efficiency 97.7% (CEC efficiency 97.1%)
- String current up to 14A
- CA Rule 21 compliant and UL 1741SB Certified
- Sunspec protocol with option cellular and WiFi
- Support module level monitoring
- Optional Built-in Revenue Grade Meter, ANSI C12.20-2010 compliance
- Fast and dynamic MPPTs and industry-leading DC voltage range
- AFCI protection, proactively reduces fire risk
- 10 years standard warranty with extension options
Application Cases
Remote Area Solar Station
Household solar energy
Industrial Solar Energy
